External Dimensions (in) Hover me Nominal external dimensions (LxWxH). Features (flanges, feet, bosses, etc.) may increase the overall dimensions. Refer to drawings/models for exact dimensional details. | 4.75 x 3.15 x 2.33 in |
External Dimensions (mm) | 121 x 80 x 59 mm |
Internal Dimensions (in) Hover me Nominal internal dimensions (LxWxH). Features (screw towers, mounting bosses, corner radii, wall draft, etc.) may impact the overall dimensions. Refer to drawings/models for exact dimensional details. | 4.42 x 2.82 x 2.17 in |
Internal Dimensions (mm) | 112 x 72 x 55 mm |
Wall Thickness Hover me Nominal wall thickness. Wall thickness may vary throughout the enclosure. Refer to drawings/models for exact details. | 0.09 in |
Weight | 0.56 lbs |
2d Drawing PDF | Download 2D Drawing PDF |
Download Material Specs | Download Material Specs |
Base | Aluminum |
Cover | Aluminum |
Assembly Screws | Steel |
Application | Indoor use |
Waterproof | No |
3D Model | AL-72P STEP |
2D Drawing DWG | AL-72P DWG |
2D Drawing PDF | AL-72P PDF |
Other Files | AL-72P Printing Template |
Aluminum Material Specs | Aluminum Specs |
Adhesive PCB Mounting Standoffs | MB-01-20 |
Customer Rating |
External Dimensions |
Country of Origin |
Color |
Material |
Application |
NEMA Ratings |
IP Ratings |
Mounting Style |
Internal Mounting Option |
Features |
4.75 x 3.15 x 2.33 in |
Taiwan, Province of China |
Natural |
Aluminum |
Indoor use |
N/A |
N/A |
|
|
|
4.53 x 2.56 x 2.17 in |
Taiwan, Province of China |
Natural or Black |
Aluminum |
Outdoor use |
|
|
|
4.38 x 3.13 x 2.00 in |
United States |
Black |
ABS |
Indoor use |
N/A |
N/A |
|
|
|
4.38 x 3.13 x 2.70 in |
United States |
Black |
ABS |
Indoor use |
N/A |
N/A |
|
|
|
