External Dimensions (in) Hover me Nominal external dimensions (LxWxH). Features (flanges, feet, bosses, etc.) may increase the overall dimensions. Refer to drawings/models for exact dimensional details. | 7.87 x 7.87 x 3.98 in |
External Dimensions (mm) | 200 x 200 x 101 mm |
Internal Dimensions (in) Hover me Nominal internal dimensions (LxWxH). Features (screw towers, mounting bosses, corner radii, wall draft, etc.) may impact the overall dimensions. Refer to drawings/models for exact dimensional details. | 7.75 x 7.75 x 3.82 in |
Internal Dimensions (mm) | 197 x 197 x 97 mm |
Wall Thickness Hover me Nominal wall thickness. Wall thickness may vary throughout the enclosure. Refer to drawings/models for exact details. | 0.06 in |
Weight | 6.15 lbs |
2d Drawing PDF | Download 2D Drawing PDF |
Steel Gauge | 16 |
Base | Carbon steel |
Cover | Carbon steel |
Gasket | Formed-in-place polyurethane |
Application | Outdoor use |
Waterproof | Yes |
3D Model | SB-39 STEP |
2D Drawing DWG | SB-39 DWG |
2D Drawing PDF | SB-39 PDF |
Other Files | SB-39 Pole Mount Kit Assembly |
Pole Mounting Kit (Installed Along Width) | PK-086 |
Pole Mounting Kit (Installed Along Length) | PK-125 |
Cable Management & Venting Accessories | Cable Glands & Vents |
Spare Key for Latch | SB-KEY-01 |
